CLASSIFICATION：
GB ER70-G/ AWS ER100S-G
DESCRIPTION：
ER100S-G is copper coated solid wire designed for all position welding highly efficient welding can be performed. The wire is supplied in precision layer winding on plastic spool.
FEATURES：
Argon-rich gas shielded welding wire for 700N/mm2 tensile grade high toughness low alloy steel, such as construction machine, pipe fitting, ship building ,Pressure vessel.
CHEMICAL ANALYSIS (RANGE) %
| Elements | C | Mn | Si | S | P | Ni | Mo | Ti | Cr | Cu |
| Guarantee range | ≤ 0.11 | 1.50~1.80 | ≤ 0.70 | ≤ 0.012 | ≤ 0.02 | 0.60~0.90 | 0.20~0.38 | 0.08~0.16 | 0.10~0.30 | ≤ 0.50 |
| Example value | 0.093 | 1.63 | 0.59 | 0.008 | 0.013 | 0.80 | 0.30 | 0.11 | 0.183 | 0.119 |
MECHANICAL PROPERTIES (RANGE)
| Item | Rm(N/mm2) | ReL/Rpo.2
(N/mm2) | A(%) | KV2(J)
-20℃ |
| Guarantee range | ≥690 | ≥ 610 | ≥ 16 | ≥ 27 |
| General results | 740 | 645 | 23 | 74,71,60 |
PACKING PARAMETERS
| Size (mm) | Net Weight (kg) | Size (mm) | Net Weight (kg) |
| 0.8 | 5/14.5/15/18/19.5/20 Spool | 1.6 | 15/20 Spool |
| 0.9 | 5/14.5/15/18/19.5/20 Spool | 2.0 | 15/20 Spool |
| 1.0 | 15/20 Spool | 3.2 | 25/50/60/100/200/250 Roll/Drum |
| 1.2 | 15/20 Spool | 4.0 | 25/50/60/100/200/250 Roll/Drum |
| 1.4 | 15/20 | 5.0 | 25/50/60/100/200/250 Roll/Drum |
ER100S-G
