CLASSIFICATION：
AWS ER44-G/TB/T 2374-2008
FEATURES：
The welding wire has excellent welding performance, and the welding bead is exquisite and beautiful.
Its deposited metal has good atmospheric corrosion resistance, crack resistance, good plasticity and toughness.
Usage suggestion：
For weathering steel structure welding.
It is mainly used for trucks, offshore project, bridges building etc.
CHEMICAL ANALYSIS (RANGE) %
| Elements | C | Mn | Si | S | P | Ni | Cr | Cu |
| Guarantee range | ≤ 0.10 | 1.40~1.80 | 0.50~0.8 | ≤ 0.025 | ≤ 0.025 | 0.20~0.50 | 0.20~0.50 | 0.2~0.50 |
| Example value | 0.057 | 1.21 | 0.56 | 0.008 | 0.016 | 0.32 | 0.31 | 0.31 |
MECHANICAL PROPERTIES (RANGE)
| Item | Rm(N/mm2) | ReL/Rpo.2
(N/mm2) | A(%) | KV2(J)
-40℃ |
| Guarantee range | ≥440 | ≥ 340 | ≥ 22 | ≥ 60 |
| General results | 535 | 450 | 26 | 139.143. 135 |
PACKING PARAMETERS
| Size (mm) | Net Weight (kg) | Size (mm) | Net Weight (kg) |
| 0.8 | 5/14.5/15/18/19.5/20 Spool | 1.6 | 15/20 Spool |
| 0.9 | 5/14.5/15/18/19.5/20 Spool | 2.0 | 15/20 Spool |
| 1.0 | 15/20 Spool | 3.2 | 25/50/60/100/200/250 Roll/Drum |
| 1.2 | 15/20 Spool | 4.0 | 25/50/60/100/200/250 Roll/Drum |
| 1.4 | 15/20 | 5.0 | 25/50/60/100/200/250 Roll/Drum |
H10MnSiCuCrNiII-ER44G
