CLASSIFICATION：
H10MnMoA/AWS /ISO14171-B-SU3M3
FEATURES：
Low Alloy welding wires,Used with high Mn,Si welding flux
Insensitive to rust on parent metals.
Formation and slagging performance well.
Usage suggestion：
Matched with 101 welding flue, for 550~600 N/mm²tensile grade parent welding.
CHEMICAL ANALYSIS (RANGE) %
| Elements | C | Mn | Si | S | P | Cr | Ni | Cu | Mo | Ti |
| Guarantee range | ≤ 0.1 | 1.20~1.60 | ≤ 0.25 | ≤ 0.03 | ≤ 0.03 | ≤ 0.20 | ≤ 0.30 | ≤0.35 | ≤0.30~0.50 | ≤0.15 |
| Example value | 0.078 | 1.34 | 0.21 | 0.008 | 0.011 | 0.064 | 0.071 | 0.16 | 0.38 | 0.089 |
MECHANICAL PROPERTIES (RANGE)
| Item | Rm(N/mm2) | ReL/Rpo.2
(N/mm2) | A(%) | KV2(J)
-20℃ |
| Guarantee range,with SJ101 | 550~700 | ≥ 470 | ≥ 20 | ≥ 27 |
PACKING PARAMETERS
| Size (mm) | Net Weight (kg) | Size (mm) | Net Weight (kg) |
| 2.4，2.5 | 25/50/60/100/200/250 Roll/Drum | 4.0 | 25/50/60/100/200/250 Roll/Drum |
| 3.2 | 25/50/60/100/200/250 Roll/Drum | 5.0 | 25/50/60/100/200/250 Roll/Drum |
